DB-9 Male to RJ-45 Female Modular Adapter

Easy Serial to Ethernet Connections

Looking for a simple way to connect your old serial device to a modern network cable? This DB-9 to RJ-45 adapter makes it easy to link serial and console equipmentlike routers, printers, and POS systemsto CAT-5 or other 8-conductor Ethernet cables. It’s ideal for home users and DIYers needing a fast and affordable serial to Ethernet adapter.

Flexible and Customizable Modular Adapter

The DB-9 male to RJ-45 female adapter lets you create custom serial cables in minutes. Just match the color-coded wires to your devices pinout and press them into the connector housingno special tools or soldering required. The modular design means this adapter can be used for a variety of setups, whether youre troubleshooting, building, or upgrading equipment.

Features and Technical Specs

• Adapter type: DB-9 male to RJ-45 female
• Pinout: 8 color-coded wires for easy assembly
• Overall dimensions: 2.0″ Long x 1.3″ Wide x 0.6″ Tall
• Includes thumbscrews for secure connection
• Requires user assemblyfully customizable for your wiring needs
• Quantity: 1 adapter per package

RJ-45 Pinout Color Codes

• Pin 1: Blue
• Pin 2: Orange
• Pin 3: Black
• Pin 4: Red
• Pin 5: Green
• Pin 6: Yellow
• Pin 7: Brown
• Pin 8: Grey

Perfect for Home and Office Use

Whether you’re adapting a serial console, printer, or another device to use standard network wiring, this compact DB-9 to RJ-45 adapter is the solution. Its cost-effective, reusable, and built with everyday consumers in mind.

Need Other Modular Adapters?

Vetco stocks a variety of modular adapters in different configurations, including DB-25, DB-15, male and female, RJ-45, and RJ-12 types. Find the right solution for any connection project.

Product ID: S-504-209
