Buzzer Piezo Round 12VDC (OV=3-24VDC) 10MA 85dB with Lead Single Tone 23x9,8mm
12VDC Buzzer Piezo Round
Specifications
- Operating Voltage Range ( VDC ) : 3.0 ~ 24.0
- Rated Voltage ( VDC ) : 12.0
- Max. Rated Current ( mA ) : 10.0
- Min. Sound Output ( dBA/ 30.0 cm ) : 85.0
- Frequency ( Hz ) : 3500.0 500.0
- Tone Nature : Single
- Operating Temperature ( C ): - 20.0 ~ + 60.0
- Stroage Temperature( C ) - 30.0 ~ + 70.0
- Terminal : Leadwire ( UL1095 , AWG#28 )
- Housing Material : ABS
- Weight ( g ) : 3.5
Downloads
- Datasheet - DB-E948
Additional Information
| Device | Buzzer |
| Type | Piezo | Round |
Buzzer Piezo Round 12VDC (OV=3-24VDC) 10MA 85dB with Lead Single Tone 23×9,8mm
12VDC Buzzer Piezo Round
Specifications
- Operating Voltage Range ( VDC ) : 3.0 ~ 24.0
- Rated Voltage ( VDC ) : 12.0
- Max. Rated Current ( mA ) : 10.0
- Min. Sound Output ( dBA/ 30.0 cm ) : 85.0
- Frequency ( Hz ) : 3500.0 500.0
- Tone Nature : Single
- Operating Temperature ( C ): – 20.0 ~ + 60.0
- Stroage Temperature( C ) – 30.0 ~ + 70.0
- Terminal : Leadwire ( UL1095 , AWG#28 )
- Housing Material : ABS
- Weight ( g ) : 3.5
Downloads
- Datasheet – DB-E948
Additional Information
| Device | Buzzer |
| Type | Piezo | Round |
