Hall-Effect Sensor Module Easy Magnetic Sensing for Arduino & DIY Projects

Simple Magnetic Field Detection with Hall-Effect Sensor Technology

Experience hassle-free magnetic sensing with this Hall-Effect Sensor Module, perfect for beginners and electronics hobbyists. Featuring the reliable Allegro A3144EUA digital Hall sensor, this module lets you easily detect the presence of a magnetic field, making it ideal for building magnetic switches, proximity sensors, security systems, and more.

How Does the Hall-Effect Sensor Module Work?

This module uses the Allegro MicroSystems A3144EUA unipolar Hall-Effect sensor. When a magnet approaches the sensor and the magnetic field strength exceeds the threshold (35-450 Gauss), the output transistor switches on, pulling the output pin low. The onboard LED indicator lights up instantly, providing visible feedback that a magnetic field is present.

• Open-collector digital output for flexible interfacing
• Fast response time for quick magnetic detection
• Threshold sensitivity: 35-450 Gauss
• Minimum hysteresis: 20 Gauss

Features & Benefits

• Simple 3-wire hookup: Signal, V+, and GND
• Wide operating voltage: 4.5V to 24V for compatibility with Arduino, Raspberry Pi, and other microcontrollers
• Compact TO-92 package for easy breadboarding or direct panel-mounting
• Clear LED indicator shows when a magnet is detected
• Perfect as a magnetic proximity sensor, contactless switch, or DIY project input

Applications

• Arduino and Raspberry Pi projects
• DIY security and alarm systems
• Magnetic switches for doors or cabinets
• Magnetic field detection in robotics
• Speed and position sensing

Technical Data Allegro A3144EUA Hall-Effect Sensor

• Sensor: Allegro MicroSystems A3144EUA (VUPN6596)
• Sensitivity: 35-450 Gauss turn-on threshold
• Hysteresis: 20 Gauss min
• Supply Voltage: 4.5V 24V DC
• Output Type: Open-collector digital output (active low)
• Package: TO-92, 3-pin
• Onboard indicator: LED

Get started with hassle-free magnetic field detection using the Allegro A3144EUA Hall-Effect Sensor Module designed for both first-time makers and experienced tinkerers!
